YS3020 Color Spectrophotometer with Customized Aperture
YS30 Series grating spectrophotometer adopts bluetooth and USB dual modes for wider use, and with SCI & SCE measurement data, it is compatible with many famous brands. 8mm, 4mm, or customized aperture is optional. Special UV light makes it YS3060 easy to measure samples with UV and high accuracy and extended function PC software let it a good partner for colorist and color quality control management.
YS3060 UV Grating Spectrophotometer
Full Illuminants + UV, 8mm&4mm Apertures, SCI&SCE, Bluetooth Comm, High Precision.
YS3020 Grating Spectrophotometer
Multi-illuminants, Customizable Aperture, SCI&SCE, Bluetooth Comm, High Precision.
YS3010 Grating Spectrophotometer
4 Illuminants, 8mm Aperture, SCI&SCE, Good Precision.
Comply with CIE No.15， GB/T 3978, GB 2893, GB/T 18833, ISO7724/1, ASTM E1164, DIN5033 Teil7, YS3010 color spectrophotometer features only 8mm single aperture. Both SCI and SCE mode makes it widely used in many applications. It has a high accuracy of 0.06 based on a white calibration plate measured 30 times at 5 seconds intervals after white calibration was performed.
| Model Items
||Reflect: di:8°, de:8°(diffused illumination, 8-degree viewing angle)
|Integrating Sphere Size
||Combined LED Light, UV Light
||Combined LED Light
||256 Image Element Double Array CMOS Image Sensor
|Measured Reflectance Range
||Dual Aperture: 10mm/8mm & 5mm/4mm
||Customized Aperture: 8mm/4mm/1×3mm
||Single Aperture: 8mm/10mm
||CIE Lab, XYZ, Yxy, LCh, CIE LUV, Hunter LAB
|Color Difference Formula
||ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00v, ΔE(Hunter)
|Other Colorimetric Index
||WI(ASTM E313, CIE/ISO, AATCC, Hunter),
YI(ASTM D1925, ASTM 313),TI(ASTM E313, CIE/ISO),
Metamerism Index MI, Staining Fastness, Color Fastness, Color Strength, Opacity, 8° Glossiness
||D65, A, C, D50, D55, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12
||D65, A, C, D50, D55, D75, F2, F7, F11
||D65, A, C, D50
||Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Offset
||Single Measurement, Average Measurement
||Camera View Finder Locating
||Li-ion battery. 5000 measurements within 8 hours
|Illuminant Life Span
||5 years, more than 3 million times measurements
||3.5-inch TFT color LCD, Capacitive Touch Screen
||USB, Bluetooth 4.0
||Standard 2000 Pcs, Sample 20000 Pcs
||0~40℃, 0~85%RH (no condensing), Altitude < 2000m
||-20~50℃, 0~85%RH (no condensing)
||Power Adapter, Built-In Li-ion Battery, User Guide, PC Software, White and Black Calibration Cavity, Dust Cover
||Micro Printer, Powder Test Box
|Notes: The specifications are subject to change without notice.
the handheld spectrophotometer can easily achieve color transferring, and be used as a precision instrument for color-matching systems. It’s widely used in plastics, electronics, painting, ink, textile and garment, printing and dyeing, printing paper, automotive, medical, cosmetics, and food industries, scientific research institutes, schools, and laboratories.
